ABB ACL30 User Manual

List of related manuals
You can find manuals and other product documents in PDF format on the Internet. See section
Document library on the Internet on the inside of the back cover. For manuals not available in the
Document library, contact your local ABB representative.
Drive manuals and guides Code (English)
ACL30 elevator drive user’s manual 3AXD50000036355
ACL30-04 elevator drive modules (2.2 to 32 kW) quick
installation guide
3AXD50000040591
Drive PC tools manuals
DriveStudio user’s manual 3AFE68749026
DriveSPC user’s manual 3AFE68836590
Application manuals and guides
Safe torque off function for ACL30 drive application guide 3AXD50000045959
2)
Option manuals and guides
FIO-01 digital I/O extension user’s manual 3AFE68784921
2)
FIO-11 analog I/O extension user’s manual 3AFE68784930
2)
FEN-01 TTL encoder interface user’s manual 3AFE68784603
2)
FEN-11 absolute encoder interface user’s manual 3AFE68784841
2)
FEN-21 resolver interface user’s manual 3AFE68784859
2)
FEN-31 HTL encoder interface user’s manual 3AUA0000031044
2)
JPC-01 network communication adapter user’s manual 3AUA0000072233
1)
1) Delivered as a printed copy with the drive or optional equipment.
2) Delivered by the Marketing Material Order Service on request (https://order.hansaprint.fi/abb/
). Accessible only inside ABB.

ABB ACL30 Specifications

General

Brand	ABB
Model	ACL30
Category	DC Drives
Language	English
