ABB ACL30 User Manual

Program features 139
 Speed reference mode set to SEP HIGH PRI or SEP LEVEL PRI
• The table below illustrates speed reference selection when 80.05 SPEED REF
MODE is set to SEP HIGH PRI or SEP LEVL PRI and all four SPEED REF SEL
parameters 80.06...80.09 are configured.
X = 0 in SEP LEVL PRI mode and 0/1 (any value) in SEP HIGH PRI mode
Y = 0/1 (any value) in SEP LEVL PRI mode and 0 in SEP HIGH PRI mode
• The table below illustrates speed reference selection in the following two
conditions:
• when parameter 80.05 SPEED REF MODE is set to SEP LEVL PRI, with
80.06 SPEED REF SEL1 = NOT USED or
• when parameter 80.05 SPEED REF MODE is set to SEP HIGH PRI, with
80.09 SPEED REF SEL4 = NOT USED
CAUTION! Broken wires or wiring mistake may lead to unexpected lift speed
selection.
When parameter 80.05 SPEED REF MODE is set to SEP LEVL PRI mode and 80.06
SPEED REF SEL1 is set to NOT USED, it is recommended to check the wiring.
80.06 SPEED
REF SEL1
80.07 SPEED
REF SEL2
80.08 SPEED
REF SEL3
80.09 SPEED
REF SEL4
Selected speed
1 0 0 X Nominal speed
0 1 0 X Medium speed
1 1 1 X Speed 2
0 1 1 X Speed 3
0 0 1 X Releveling speed
Y Y Y 1 Leveling speed
0 0 0 0 Speed 1
80.05 SPEED REF MODE - SEP LEVL PRI
80.06 SPEED REF SEL1 - NOT USED
80.05 SPEED REF MODE - SEP HIGH PRI
80.09 SPEED REF SEL4 - NOT USED
Selected
speed
SPEED REF
SEL2
SPEED REF
SEL3
SPEED REF
SEL4
SPEED REF
SEL1
SPEED REF
SEL2
SPEED REF
SEL3
0 0 0 1 0 0 Nominal speed
1 0 00 10 Medium speed
N/A N/A N/A 1 1 1 Speed 2
1 1 0 0 1 1 Speed 3
0 1 00 01 Releveling
speed
0/1 0/1 1 0 0 0 Leveling speed
N/A N/A N/A N/A N/A N/A Speed 1
