Dimension drawings 347
Dimension drawings
Contents of this chapter
Dimension drawings of the drive module and related accessories are shown below.
The dimensions are given in millimetres and [inches].
See,
• Frame size B on page 348
• Frame size C on page 350
• Frame size D on page 352
• Mains chokes – CHK-0x on page 353
• EMC filters – JFI-0x on page 354
• Brake resistors – JBR-xx on page 356
