Technical data 319
Technical data
Contents of this chapter
This chapter contains the technical specifications of the drive, e.g. the ratings, sizes
and technical requirements, and provisions for fulfilling the requirements for CE and
other markings.
Drive specifications
Drive type
ACL30-04...
Frame
size
Typical
motor
power
1
kW
Output ratings Mains choke EMC filter
I
2N
2
I
2max
3
A A
-06A0 B 2.2 6 11 CHK-02 JFI-02
-09A0 B 3 9 16 CHK-03 JFI-03
-013A B 5.5 13 22 CHK-03 JFI-03
-017A B 7.5 17 28 CHK-04 JFI-03
-023A C 11 23 36 CHK-05
4
/Internal JFI-05
-030A C 14 30 46 CHK-05
4
/Internal JFI-05
-050A D 22 50 80 CHK-07
4
/Internal JFI-07
-070A D 32 70 110 CHK-08
4
/Internal JFI-07
1
To achieve the rated motor power as in the above table, the rated current of the drive must be higher than
or equal to the rated motor current.
2
I
2N
Nominal output current at 40 °C (104 °F).
3
I
2max
Maximum short-time output current. See Cyclic loads below.
4
Internal mains choke is an option for C and D frames.
