Page #166 background image
166 Program features
Relay outputs
The drive has one relay output. Two additional relay outputs can be added by using
an FIO-01 I/O extension (enabled with parameter 12.80 EXT IO SEL). For more
information on the I/O extension, see FIO-01 digital I/O extension user’s manual
(3AFE68784921 [English]).
Settings
Diagnostics
Parameters Additional information
12.07 RO1 OUT PTR Selects a drive signal to be connected to relay output RO1.
12.80 EXT IO SEL Activates an I/O extension installed into Slot 2.
12.89 EXT RO1 OUT PTR Selects a drive signal to be connected to extended relay output EXT
RO1.
12.90 EXT RO2 OUT PTR Selects a drive signal to be connected to extended relay output EXT
RO2.
Actual signals Additional information
02.02 RO STATUS Status of the relay output.
02.81 EXT RO STATUS Status of the extended relay outputs.
