340 EMC filters
WARNING! An EMC filter must not be installed if the drive is connected to
an IT power system (i.e. an ungrounded, or a high resistance grounded
[over 30 ohm] power system) or a corner-grounded TN system.
Selecting EMC filters
Degree of protection
IP20
Dimensions and weights
See dimension drawing of EMC filters – JFI-0x on page 354.
For data of dimensions, wire sizes and tightening torques, see EMC filter – JFI-0x
dimensions on page 355.
Drive type
ACL30-04...
Frame Filter type
EN 61800-3: 2004 Category C2
-06A0 B JFI-02*
-09A0 B JFI-03*
-013A
-017A
-023A C JFI-05*
-030A
-050A D JFI-07*
-070A
*External filter; to be ordered separately
