ABB ACL30 User Manual

328 Technical data
Materials
Drive enclosure • PC/ABS, colour NCS 1502-Y (RAL 9002 / PMS 420 C)
• hot-dip zinc coated steel sheet
• extruded aluminium AlSi.
Packaging Corrugated cardboard, PP bands.
Disposal The drive contains raw materials that should be recycled to preserve
energy and natural resources. The package materials are environmentally
compatible and recyclable. All metal parts can be recycled. The plastic
parts can either be recycled or burned under controlled circumstances,
according to local regulations. Most recyclable parts are marked with
recycling marks.
If recycling is not feasible, all parts excluding electrolytic capacitors and
printed circuit boards can be landfilled. The DC capacitors contain
electrolyte, which is classified as hazardous waste within the EU. They
must be removed and handled according to local regulations.
For further information on environmental aspects and more detailed
recycling instructions, please contact your local ABB distributor.
Applicable standards
The drive complies with the following standards. The compliance with the
European Low Voltage Directive is verified according to standards
EN 50178 and EN 60204-1.
EN 50178 (1997) Electronic equipment for use in power installations
IEC 60204-1
(2005), modified
Safety of machinery. Electrical equipment of machines. Part 1: General
requirements. Provisions for compliance: The final assembler of the
machine is responsible for installing
- an emergency-stop device
- a supply disconnecting device
- the ACL30 into a cabinet.
EN 60529: 1991
(IEC 60529)
Degrees of protection provided by enclosures (IP code)
IEC 60664-1
(2007), Edition
2.0
Insulation coordination for equipment within low-voltage systems. Part 1:
Principles, requirements and tests.
IEC 61800-3
(2004)
Adjustable speed electrical power drive systems. Part 3: EMC
requirements and specific test methods.
EN 61800-5-1
(2003)
Adjustable speed electrical power drive systems.
Part 5-1: Safety requirements. Electrical, thermal and energy
Provisions for compliance: The final assembler of the machine is
responsible for installing the ACL30 in a cabinet that is protected to IP2X
(IP3X for top surfaces for vertical access).
prEN 61800-5-2 Adjustable speed electrical power drive systems.
Part 5-2: Safety requirements. Functional
