Dimension drawings 355
EMC filter – JFI-0x dimensions
Parameter Filter type
JFI-02 JFI-03 JFI-05 JFI-07
Dim. A mm (in.) 250 (9.84) 250 (9.84) 250 (9.84) 270 (10.63)
Dim. B mm (in.) 45 (1.77) 50 (1.97) 85 (3.35) 90 (3.54)
Dim. C mm (in.) 70 (2.76) 85 (3.35) 90 (3.54) 150 (5.91)
Dim. D mm (in.) 220 (8.66) 240 (9.45) 220 (8.66) 240 (9.45)
Dim. E mm (in.) 235 (9.25) 255 (10.04) 235 (9.25) 255 (10.04)
Dim. F mm (in.) 25 (0.98) 30 (1.18) 60 (2.36) 65 (2.56)
Dim. G mm (in.) 5.4 (0.21) 5.4 (0.21) 5.4 (0.21) 6.5 (0.26)
Dim. H mm (in.) 1 (0.04) 1 (0.04) 1 (0.04) 1.5 (0.06)
Dim. I mm (in.) 22 (0.87) 25 (0.98) 39 (1.54) 45 (1.77)
Dim. J M5 M5 M6 M10
Dim. K mm (in.) 22.5 (0.89) 25 (0.98) 42.5 (1.67) 45 (1.77)
Dim. L mm (in.) 29.5 (1.16) 39.5 (1.56) 26.5 (1.04) 64 (2.52)
Weight kg (lbs) 0.8 (1.75) 1.1 (2.4) 1.8 (4.0) 3.9 (8.5)
Wire size (solid)
mm
2
(AWG)
0.2 10
(AWG24…8)
0.5 16
(AWG20…6)
6…35
(AWG8…2)
16…50
(AWG4…1/0)
Wire size (stranded)
mm
2
(AWG)
0.2 6
(AWG24…10)
0.5 10
(AWG20…8)
10…25
(AWG6…4)
16…50
(AWG4…1/0)
Tightening torque of
terminals N·m (lbf·in)
1.5 1.8
(13.3 15.9)
1.5 1.8
(13.3 15.9)
4.0 4.5
(35 40)
7…8
(60…70)
