44 Mechanical installation
Unpacking
The drive is delivered in a cardboard box. To open, remove any banding and lift the
top off the box.
Check that the box contains...
ACL30 drive module, with factory-installed options
Three cable clamp plates (two for power cabling, one for control cabling) with screws
Screw-type terminal blocks required to be attached to the headers on the JCU control
unit and the power unit
