Using the control panel 95
Output mode
In the Output mode, you can:
• monitor actual values of up to three signals
• change the direction of the motor rotation
• set the speed reference
• adjust the display contrast
• start, stop, change the direction and switch between local and remote control.
You get to the Output mode by pressing repeatedly.
The top right corner of the display shows the
reference value. The center can be configured to
show up to three signal values or bar graphs; see
page 95 for instructions on selecting and modifying
the monitored signals.
 Changing the direction of motor rotation in Output mode
Step Action Display
1. If you are not in the Output mode, press
repeatedly until you get there.
2. If the drive is in remote control (REM shown on the
status line), switch to local control by pressing
. The display briefly shows a message about
changing the mode and then returns to the Output
mode.
3. To change the direction from forward ( shown on
the status line) to reverse ( shown on the status
line), or vice versa, press .
EXIT
50 A
10 Hz
7 %10.
0.
49.
LOC
DIR
MENU00:00
30.00rpm
EXIT
50 A
10 Hz
7 %10.
0.
49.
REM
DIR
MENU
00:00
30.00rpm
LOC
REM
50 A
10 Hz
7 %10.
0.
49.
LOC
DIR
MENU00:00
30.00rpm
DIR
