Technical data 323
Supply cable fuses
Fuses for short circuit protection of the supply cable are listed below. The fuses also
protect the adjoining equipment of the drive in case of a short circuit. Check that the
operating time of the fuse is below 0.5 seconds. The operating time depends on the
supply network impedance and the cross-sectional area and length of the supply
cable. See also chapter Planning the electrical installation.
Note: Fuses with a higher current rating must not be used.
Drive type
ACL30-04...
Input
current
(A)
IEC fuse UL fuse Cross-sectional
area of cable
Rated
current
(A)
Volta
ge (V)
Class Rated
current
(A)
Volta
ge (V)
UL
Class
mm
2
AWG
-06A0 7.0* 10 500 gG 10 600 T 1.5 … 4 16…12
-09A0 10.5* 16 500 gG 15 600 T 1.5 … 10 16…8
-013A 15.2* 20 500 gG 20 600 T 1.5 … 10 16…8
-017A 19.8* 25 500 gG 25 600 T 1.5 … 10 16…8
-023A 17.7 25 500 gG 25 600 T 6 ... 35 9…2
-030A 23.0 32 500 gG 35 600 T 6 ... 35 9…2
-050A 41.8 50 500 gG 50 600 T 10 ... 70 6…2/0
-070A 58.4 80 500 gG 80 600 T 10 ... 70 6…2/0
*Without mains choke
PDM-00425726
