ABB ACL30 User Manual

Parameters 185
Parameter groups 01…09
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
01
01 ACTUAL
VALUES
Basic signals for monitoring the drive.
All signals in this group are read-only, unless
otherwise specified.
01.01 SPEED ACT
Shows the filtered actual speed.
Used speed feedback is defined by parameter
22.01 SPEED FB SEL. Filter time constant can be
adjusted by parameter 22.02 SPEED ACT FTIME.
- / Real
-30000.00…
30000.00 rpm
Actual speed in rpm. - /
100 = 1 rpm
01.02 SPEED ACT PERC
Shows the actual speed in percent of motor
synchronous speed.
- / Real
-1000.00…
1000.00%
Actual speed in percent. - / 100 = 1%
01.03 FREQUENCY
Shows the estimated drive output frequency. - / Real
-30000.00…
30000.00 Hz
Output frequency in Hz. - /
100 = 1 Hz
01.04 CURRENT
Shows the measured motor current. - / Real
0.00…30000.00 A
Motor current in A. - / 100 = 1 A
01.05 CURRENT PERC
Shows the motor current in percent of nominal motor
current.
- / Real
0.0…1000.0% Motor current in percent 10 = 1%/ -
01.06 TORQUE
Shows motor torque in percent of motor nominal
torque.
- / Real
-1600.0…1600.0%
Motor torque in percent 10 = 1%/ -
01.07 DC-VOLTAGE
Shows the measured intermediate circuit voltage. - / Real
0.00…2000.00 Intermediate circuit voltage - /
100 = 1 V
01.08 ENCODER SPEED
Shows the encoder speed. - / Real
-32768.00...
32768.00 rpm
Encoder speed in rpm. - /
100 = 1 rpm
01.09 ENCODER POS
Shows the actual position of encoder within one
revolution.
- / Real24
0.00000000...
1.00000000 rev
Encoder position within one revolution. - /
100000000
= 1 rev
