ABB ACL30 - Speed Reference Mode Set to MULTIPLE

138 Program features
The function selects the speed reference based on the elevator operation mode as
follows.
• If neither the evacuation mode nor the inspection mode is active, the speed
reference is selected based on the combined status of parameters 80.05 SPEED
REF MODE, 80.06 SPEED REF SEL1, 80.07 SPEED REF SEL2, 80.08 SPEED
REF SEL3, and 80.09 SPEED REF SEL4.
• If either the evacuation mode or the inspection mode is active, the speed
reference is selected with parameter 80.16 EVACUATION SPEED or 80.15
INSPECTION SPEED, depending on which of the modes is active.
• If both the evacuation mode and the inspection mode are active, the evacuation
mode has higher priority.
 Speed reference mode set to MULTIPLE
The table below further illustrates speed reference selection when 80.05 SPEED REF
MODE is set to MULTIPLE.
10.81
EVACUATION
MODE
10.84
INSPECTION
MODE
80.06 SPEED
REF SEL1
80.07 SPEED
REF SEL2
80.08 SPEED
REF SEL3
05.03 LIFT SPEED SEL
0 0 0 0 0 Speed1 (zero speed)
0 0 1 0 0 Nominal speed
0 0 0 1 0 Medium speed
0 0 1 1 0 Leveling speed
0 0 0 0 1 Releveling speed
0 0 1 0 1 Inspection speed
0 0 0 1 1 Speed2
0 0 1 1 1 Speed3
0 1 x x x Inspection speed
1 x x x x Evacuation speed
