ABB ACL30 User Manual

Parameters 201
05.02 LIFT FW
Lift fault status word with fault bits. - / Pb
0x0000...0xFFFF Lift fault status word with fault bits. 1 = 1
05.03 LIFT SPEED SEL
- / Real
-32768.00...
32768.00 m/s
Lift speed reference.
-/ 100 = 1 m/s
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
Bit Name Value Information
0 SPEED MATCH 1 The speed error is higher than defined with
parameter 81.02 SPD STD DEV LVL in the
steady state or defined with parameter 81.03
SPD RMP DEV LVL in the ramp state, and the
time delay defined with parameter 81.04
SPEED MATCH DLY has elapsed.
0 The speed error is within the defined limits (no
SPEED MATCH fault active).
1 TORQUE PROVE 1 The drive was not able to provide sufficient
torque during a torque proving sequence.
0 Torque proving successfully accomplished or
torque proving disabled (no TORQUE PROVE
fault active).
2 BRAKE SLIP 1 The brake slipped while a torque proving
sequence was taking place.
0 No brake slip detected during torque proving
(no BRAKE SLIP fault active).
3 MOTOR STALL 1 81.07STALL SPEED LIM,and the time period
defined with parameter 81.08 STALL FAULT
DLY has elapsed.
0 No MOTOR STALL fault active.
NOT USED
9 OVERCURRENT 1 Output current has exceeded the internal limit.
0 Output current is within the internal limit.
10 OVERVOLTAGE 1 Excessive intermediate circuit DC voltage.
0 Intermediate circuit DC voltage is sufficient.
11 UNDERVOLTAGE 1 Intermediate circuit DC voltage is not
sufficient.
0 Intermediate circuit DC voltage is sufficient.
12 EXTERNAL FAULT 1 Fault in the external device.
0 No fault in the external device.
13 NOT USED
