ABB ACL30 User Manual

202 Parameters
05.04 LIFT SPEED ACT
Shows the actual lift speed in m/s. - / Real
-32768.00...
32768.00 m/s
Actual life speed.
- /100 = 1 m/s
05.05 LIFT SPEED REF
Shows the ramped and shaped speed reference in
m/s.
- / Real
-32768.00...
32768.00 m/s
Lift speed reference.
- /100 = 1 m/s
05.06 LVL DISTANCE
ACT
Shows the distance traveled by the lift during leveling. - / Real
-32768.00...
32768.00 m
Actual distance traveled by the lift.
- / 100 = 1 m
05.07 FLOOR DISTANCE
Shows the distance between two floors. - / Real
-32768.00...
32768.00 m
Distance between two floors
- / 100 = 1 m
05.08 EVACUATION DIR
Shows the direction of the lighter load measured
during automatic evacuation.
- / enum
DOWN Evacuation is towards downward direction.
0
UP Evacuation is towards upward direction.
1
05.09 START UP COUNT
Shows the number of times the drive was switched on
i.e power on/off.
- / Real
0...2147483647 Drive power on count.
1 = 1
05.10 TRIP COUNT
Shows the number of times the lift started/travelled
between floors.
- / Real
0...2147483647 Lift start up count.
1 = 1
05.11 PEAK CURRENT
ACC
Shows the peak current acceleration. - / Real
-32768.0...
32768.0 A
Peak current acceleration.
10 = 1 A
05.12 PEAK CURRENT
DEC
Shows the peak current deceleration. - / Real
-32768.0...
32768.0 A
Peak current deceleration.
10 = 1 A
05.13 RESET COUNTER
Resets the lift counters for start up count and trip
count.
DONE /
enum
DONE Lift counters reset is done.
0
START UP CNT Start up counter in parameter 05.09 START UP
COUNT is reset.
1
TRIP COUNTER Start up counter in parameter 05.10 TRIP COUNT is
reset.
2
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
