322 Technical data
Dimensions and weights
See also chapter Dimension drawings on page 347.
Note: The wiring to the I/O options requires some 50 mm (2”) of additional depth.
Noise levels
Frame
size
Height
(without
cable clamp
plates)
Height
(with cable
clamp
plates)
Width Depth
(without
options
installed
on JCU)
Depth
(with options
installed on
JCU)
Weight
mm (in.) mm (in.) mm (in.) mm (in.) mm (in.) kg (lbs)
B 380 (14.96) 476 (18.74) 100 (3.94) 223 (8.78) 246 (9.69) 4.8 (10.6)
C 467 (18.39) 558 (21.97) 165 (6.50) 225 (8.85) 248 (9.76) 10 (22.0)
D 467 (18.39) 644 (25.34) 220 (8.66) 225 (8.85) 248 (9.76) 17 (37.5)
Frame size Noise level dBA
B39
C40
D40
