Planning the cabinet installation 37
Main dimensions and free space requirements
The main dimensions of the drive modules as well as free space requirements are
presented below. For more details, refer to chapter Dimension drawings on page 347.
220 [8.66"]
165 [6.50"]
100 [3.94"]
5.2 [0.20"]
18.7 [0.74"]
64.2 [2.53"] 65.7 [2.59"]
353 [13.90"]
474 [18.66"] 476 [18.73"]
151 [5.94"]
107 [4.2"]356 [14.02"]
61.4 [2.42"]
557.8 [21.96"] 643.8 [25.34"] 466.6 [18.37"]
Frame D Frame C Frame B
