Parameters 219
Freq input DIO2 is used as a frequency input. 2
12.03 DIO3 CONF
Selects whether DIO3 is used as a digital input, as a
digital output or as a frequency output.
Output/
enum
Output DIO3 is used as a digital output. 0
Input DIO3 is used as a digital input. 1
Freq output DIO3 is used as a frequency output. 3
12.04 DIO1 OUT PTR
Selects a drive signal to be connected to digital
output DIO1 (when 12.01 DIO1 CONF is set to
Output).
See parameter 06.02 STATUS WORD 2, bit 2.
C.False/
Bit pointer
Bit pointer: CONST or POINTER (See Terms and
abbreviations on page 183.)
1 = 1
12.05 DIO2 OUT PTR
Selects a drive signal to be connected to digital
output DIO2 (when 12.02 DIO2 CONF is set to
Output).
See parameter 06.02 STATUS WORD 2, bit 3.
READY/
Bit pointer
READY Parameter 06.01 STATUS WORD 1, bit 0.
ENABLED Parameter 06.01 STATUS WORD 1, bit 1.
STARTED Parameter 06.01 STATUS WORD 1, bit 2.
RUNNING Parameter 06.01 STATUS WORD 1, bit 3.
FAULT Parameter 06.01 STATUS WORD 1, bit 10.
NOT FAULTED Parameter 06.01 STATUS WORD 1, bit 12.
12.06 DIO3 OUT PTR
Selects a drive signal to be connected to digital
output DIO3 (when 12.03 DIO3 CONF is set to
Output).
See parameter 06.01 STATUS WORD 1, bit 10.
FAULT/
Bit pointer
See description in parameter 12.05 DIO2 OUT PTR. 1 = 1
12.07 RO1 OUT PTR
Selects a drive signal to be connected to relay output
RO1.
See parameter 03.06 CONTROL VALUES, bit 0.
BRAKE
CMD/
Bit pointer
BRAKE CMD
Parameter 03.06 BRAKE COMMAND.
READY
Parameter 06.01 STATUS WORD 1, bit 0.
ENABLED Parameter 06.01 STATUS WORD 1, bit 1.
STARTED Parameter 06.01 STATUS WORD 1, bit 2.
RUNNING Parameter 06.01 STATUS WORD 1, bit 3.
FAULT Parameter 06.01 STATUS WORD 1, bit 10.
NOT FAULTED Parameter 06.01 STATUS WORD 1, bit 12.
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
