ABB ACL30 User Manual

218 Parameters
10.87 LIFT CW
Lift control word for fieldbus control. 0x0000/
UINT32
0x0000…0xFFFF Control word. - / 1 = 1
10.88 EVAC REC CUR
LIM
Defines the recommended evacuation current limit. 10 %/ Real
0...100 %
Evacuation current limit.
1 = 1
10.89 EVAC REC DIR
MEM
Shows the recommended evacuation direction. FORWARD/
enum
FORWARD
Forward direction 0
BACKWARD
Reverse direction 1
12
12 DIGITAL IO
Settings for the digital inputs and outputs, and the
relay output.
12.01 DIO1 CONF
Selects whether DIO1 is used as a digital input or as
a digital output.
Input/
enum
Output DIO1 is used as a digital output. 0
Input DIO1 is used as a digital input. 1
12.02 DIO2 CONF
Selects whether DIO2 is used as a digital input, as a
digital output or as a frequency input.
Output/
enum
Output DIO2 is used as a digital output. 0
Input DIO2 is used as a digital input. 1
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
Bit Name Value Information
0 START UP 1 Start command is active in the upward direction.
0 Start command is inactive in the upward direction.
1 START DOWN 1 Start command is active in the downward direction.
0 Start command is inactive in the downward direction.
2 INSPECT
START UP
1 Inspection mode is enabled in the upward direction.
0 Inspection mode is disabled in the upward direction.
3 INSPECT
START DN
1 Inspection mode is enabled in the downward direction.
0 Inspection mode is disabled in the downward direction.
4 SPEED REF
SEL1
1 Speed selection bit 1 is enabled.
0 Speed selection bit 1 is disabled.
5 SPEED REF
SEL2
1 Speed selection bit 2 is enabled.
0 Speed selection bit 2 is disabled.
6 SPEED REF
SEL3
1 Speed selection bit 3 is enabled.
0 Speed selection bit 3 is disabled.
7 RUN ENABLE 1 Run enable signal is active.
0 Run enable signal is inactive.
8 FAULT RESET 1 Fault reset signal is active.
0 Fault reset signal is inactive.
9…15 NOT USED
