ABB ACL30 User Manual

212 Parameters
08.16 ALARM WORD 6
Alarm word 6. For possible causes and remedies, see
chapter Fault tracing.
-/ UINT32
0x0000...0xFFFF Alarm word 6 1 = 1 / -
09
09 SYSTEM INFO
Drive type, program revision and option slot
occupation information.
09.01 DRIVE TYPE Shows the drive application type. - / INT32
0...65535 Inverter type 1 = 1
09.02 DRIVE RATING ID
Shows the inverter type of the drive.
Value is drive dependent.
- / INT32
0...65535 Inverter type 1 = 1
09.03 FIRMWARE ID
Shows the firmware name. Eg, UMFL. - / Pb
1 = 1
09.04 FIRMWARE VER
Shows the version of the firmware package in the
drive, eg, 0x1510.
- / Pb
1 = 1
09.05 FIRMWARE
PATCH
Shows the version of the firmware patch in the drive. -/ Pb
1 = 1
0...4294967295 Firmware patch version 1 = 1
09.10 INT LOGIC VER
Shows the version of the logic in the power unit
interface.
-/ Pb
- / 1 = 1
09.11 SLOT 1 VIE NAME
Shows the VIE name in slot 1. -/ Real
1 = 1
09.12 SLOT 1 VIE VER
Shows the VIE version in slot 1. -/ Real
1 = 1
09.13 SLOT 2 VIE NAME
Shows the VIE name in slot 2. -/ Real
1 = 1
09.14 SLOT 2 VIE VER
Shows the VIE version in slot 2. -/ Real
1 = 1
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
Bit Alarm
0…1 RESERVED
2 LOW VOLT MOD CON
3…9 RESERVED
10 BR DATA
11 ENC NO POS OFFS
12 SUPPL PHS LOSS
13 PU LOST
14…15 RESERVED
