ABB ACL30 User Manual

24 About the manual
FEN-01 Optional TTL encoder interface module
FEN-11 Optional absolute encoder interface module
FEN-21 Optional resolver interface module
FEN-31 Optional HTL encoder interface module
FIO-01 Optional digital I/O extension module
FIO-11 Optional analogue I/O extension module
FIO-21 Optional analog/digital I/O extension module
FLON-01 Optional L
ONWORKS
®
adapter module
FPBA-01 Optional PROFIBUS DP adapter module
Frame (size) Size of the drive module. This manual deals with frames B, C and D. To
determine the frame size of a drive module, refer to the drive designation
label attached to the drive, or the Drive specifications on page 319.
FSCA-0x Optional Modbus/RTU adapter module
IGBT Insulated Gate Bipolar Transistor; a voltage-controlled semiconductor type
widely used in inverters due to their easy controllability and high switching
frequency.
I/O Input/Output
ID run Motor identification run. During the identification run, the drive will identify
the characteristics of the motor for optimum motor control.
JBR-xx Series of optional brake resistors
JCU Control unit of the drive module. The JCU is installed on top of the power
unit. The external I/O control signals are connected to the JCU, or optional
I/O extensions mounted on it.
Jerk Rate of change of acceleration/deceleration
JFI-xx Series of optional EMC filters
JMU Memory unit attached to the control unit of the drive
JPU Power unit; see the definition below.
Parameter User-adjustable operation instruction to the drive, or signal measured or
calculated by the drive
PI controller Proportional-Integral Controller
PLC Programmable Logic Controller. Also referred to as elevator controller in this
manual.
Power unit Contains the power electronics and connections of the drive module. The
JCU is connected to the power unit.
RFG Ramp Function Generator
RFI Radio-frequency interference
RO Relay Output. Interface for a digital output signal. Implemented with a relay.
SSI Synchronous Serial Interface
STO Safe Torque Off
Term/
abbreviation
Definition
