ABB ACL30 User Manual

260 Parameters
58.21 RAW CW LSW
Shows the LSW part of the Control Word which the
drive receives from the Modbus master. This
parameter is read-only.
0x0000 /
Pb
0x0000…0xFFFF
Bits 0…15 of the Control word as a hex value.
1 = 1
58.22 RAW CW MSW
Shows the MSW part of the Control Word which the
drive receives from the Modbus master. This
parameter is read-only.
0x0000 /
Pb
0x0000…0xFFFF
Bits 16…32 of the Control word as a hex value.
1 = 1
58.23 RAW SW LSW
Shows the LSW part of the Status Word which the
drive sends to the Modbus master.
This parameter is read-only.
0x0000 /
Pb
0x0000…0xFFFF
Bits 0…15 of the Status word as a hex value.
1 = 1
58.24 RAW SW MSW
Shows the MSW part of the Status Word which the
drive sends to the Modbus master. This parameter is
read-only.
0x0000 /
Pb
0x0000…0xFFFF
Bits 16…32 of the Status word as a hex value.
1 = 1
58.25 RAW REF 1 LSW
Shows the LSW part of reference 1 which the drive
receives from the Modbus master.
This parameter is read-only.
0x0000 /
Pb
0x0000…0xFFFF
Bits 0…15 of reference 1 as a hex value.
1 = 1
58.26 RAW REF 1 MSW
Shows the MSW part of reference 1 which the drive
receives from the Modbus master.
This parameter is read-only.
0x0000 /
Pb
0x0000…0xFFFF
Bits 16…32 of reference 1 as a hex value.
1 = 1
58.27 RAW REF 2 LSW
Shows the LSW part of reference 2 which the drive
receives from the Modbus master.
This parameter is read-only.
0x0000 /
Pb
0x0000…0xFFFF
Bits 0…15 of reference 2 as a hex value.
1 = 1
58.28 RAW REF 2 MSW
Shows the MSW part of reference 2 which the drive
receives from the Modbus master.
This parameter is read-only.
0x0000 /
Pb
0x0000…0xFFFF
Bits 16…32 of reference 2 as a hex value.
1 = 1
58.30 TRANSMIT DELAY
Defines the delay time which the slave waits until it
sends a response.
0x0000/
Real
0…65335 ms
Transmit delay time.
1 = 1 ms
58.31 RET APP ERRORS
Selects the status of whether the drive returns the
Modbus exception codes or not.
YES /
enum
NO Not returned.
0
YES Drive returned the Modbus exception code.
1
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
