Parameters 261
58.32 WORD ORDER
Defines the order of the data words in the Modbus
frame.
LSW MSW /
enum
MSW LSW Most significant word first, then Least significant
word.
0
LSW MSW Least significant word first, then Most significant
word.
1
58.35 DATA I/O 1
Defines the address of the drive parameter which the
Modbus master accesses when it reads from or
writes to the register address corresponding to
Modbus In/Out parameter no. 1. The Modbus master
defines the type of the data (input or output).
The value is conveyed in a Modbus frame using two
16-bit words. If the drive parameter is a 16-bit value,
the LSW (Least significant word) conveys the value.
If the drive parameter is a 32-bit value, the next
Modbus In/Out parameter is also RESERVED.
- / Real
0…9999
Parameter address. Format: xxyy, where:
xx = parameter group
yy = parameter index
1 = 1
58.36 DATA I/O 2
See parameter 58.35.
- / Real
0…9999
See parameter 58.35.
1 = 1
……
…
…
58.58 DATA I/O 24
See parameter 58.35.
- / Real
0…9999
See parameter 58.35.
1 = 1
72
72 INTERNALLY
USED
Internally used. Cannot be set by the user.
72.01 JOG1 START
Internally used. Cannot be set by the user.
72.02 FAULT RESET SEL
Internally used. Cannot be set by the user.
72.03 EM STOP OFF3 Internally used. Cannot be set by the user.
72.04 FB CW USED
Selects the source for the control word when fieldbus
(FBA) is selected as the start and stop control
location (see parameter 10.01 START FUNC). By
default, the source is from parameter 02.10 FBA
MAIN CW.
Note: This parameter cannot be changed while the
drive is running.
P.FB A M AIN
CW/
Val pointer
Value pointer (See Terms and abbreviations on page 184.)
72.05 JOG2 START
Internally used. Cannot be set by the user.
72.06 JOG ENABLE
Internally used. Cannot be set by the user.
72.07 START ENABLE
Internally used. Cannot be set by the user.
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
