76 Installation checklist
The supply (input power) is connected to U1/V1/W1 (UDC+/UDC- in case of a DC
supply) and the terminals are tightened to specified torque. (See Electrical installation:
Connecting the power cables and Installing power cable clamp plates.)
Appropriate supply (input power) fuses and disconnector are installed. (See Technical
data: Supply cable fuses and Planning the electrical installation: Selecting the supply
disconnecting device.)
The motor is connected to U2/V2/W2, and the terminals are tightened to specified
torque. (See Operation principle and hardware description: Main circuit.)
The brake resistor (if present) is connected to R+/R-, and the terminals are tightened to
specified torque. (See Electrical installation: Connection diagram.)
The motor cable (and brake resistor cable, if present) is routed away from other cables.
(See Planning the electrical installation: Routing the cables.)
There are no power factor compensation capacitors in the motor cable.
The external control connections to the JCU control unit are Ok. (See Electrical
installation: Connecting the control cables: JCU control unit.)
There are no tools, foreign objects or dust from drilling inside the drive.
Motor connection box and other covers are in place.
Check that...
