MODULE 1: SYSTEM TOUR
1-12 AEROSET
®
Customer Training Guide
94858-103 — July 2003
NOTE: Components marked with an asterisk (*) are not
shown on the illustrations. Your instructor will show you
these components.
13*
Sample Carousel
Movement Indicator
Light
• Blinking red - carousel is moving.
• Solid red - Sample Arm is aspirating a sample.
•Off - idle.
14*
STAT Sampling
Indicator Light
Indicates when a STAT sample is being aspirated.
The Operator may add samples when the light is not illuminated.
15*
FastTrack™
Sampler Indicator
Lights LEDs
Tray Status LED - indicates the presence, status, and movement of the
Sample Carrier Trays.
• Blinking orange - FastTrack Sampler is not in the home position.
• Solid blue - indicates the presence of a Sample Carrier Tray to the
right of the sampling area. The blue lights will blink when the
FastTrack is moving.
Carrier Entry Position LED
- indicates the position where the Sample
Carrier will be moved into the AEROSET System for sample
aspiration. The red arrow illuminates when the Sample Carrier is in
the sampling position.
16*
Front Display Panel Indicates the Power status and FastTrack Sampler status.
• Refrig - Main Circuit Breaker Switch is ON.
•Auto - Rotary Power Switch is in the Auto position.
•Power - Main Circuit Breaker Switch is ON and the Rotary
Power Switch is in the ON position.
• Run - samples are being aspirated from the FastTrack Sampler.
• Rerun - samples are automatically returned to the sampling area for
rerun.
• Remove - a Sample Carrier Tray has hit one of the bumpers
(> 4 loaded).
• Set - it is OK to add Sample Carrier Trays to the FastTrack
Sampler.
17*
Local User Interface
(LUI)
Control Panel on the Analyzer, used to initiate movement of the
FastTrack Sampler and Reagent Supply Centers.
• Tray Home - homes the FastTrack Sampler.
• Remove Rack - will remove the Sample Carrier from the sampling
area.
• R1/R2 - when illuminated it is OK to access the particular Reagent
Supply Center.
When these buttons are first pressed, the Reagent Supply Center
homes. Pressing these buttons again rotates the center 1/3 of a turn.
•Tray → or ← - moves the FastTrack Sampler one position to the
right or left.
