Accessing the Levey-Jennings Graph Screen from the QC SUMMARY Screen
The Levey-Jennings Graph screen for an assay can be accessed from
the QC SUMMARY screen by performing the following steps:
1. Select the line that displays the QC statistics of the assay desired.
2. Select <LJ Graph> in the right-hand column. The Levey-Jennings
Graph screen for the selected assay is displayed.
Selecting Date Range
A specific date range can be configured on the QC SUMMARY screen
to calculate QC statistics.
1. In the right column of the QC SUMMARY screen, select
<D.Range>. The Date Range dialog window displays.
2. Enter the date range then select <ON> to confirm the selection. The
Date Range dialog window displays.
3. Select <OK>. Statistics for the selected date range of the
highlighted assay display.
NOTE: A value within the defined date range displays as a
blue dot on the Levey-Jennings graph. A value outside the
defined date range displays as a gray dot on the graph.
NOTE: The pink update button will display to alert the
Operator that statistics were changed. Press <Update> to
clear the button.
• When a date range is activated for an assay, the
text is blue.
• The date range will display on the “from__/__/
__ to __/__/__” below the D.Range button
when the assay is highlighted on the QC
SUMMARY screen.
• If multiple assays are selected on the QC
SUMMARY screen with an activated date
range, “from__/__/__ to __/__/__” will be blank.
