EKI-7710 Series User Manual 127
Port Info Port 32 Link
Up Counter
1 word 16 bits HEX 0x171F 35920
PoE Voltage 1 word 16 bits HEX 0x1800 ~
0x181F
36145 ~
36176
PoE Voltage (V)
Ex: poe voltage = 5
Received MODBUS
response: 0x0005
Port 1 PoE
Voltage
1 word 16 bits HEX 0x1800 36145
Port 2 PoE
Voltage
1 word 16 bits HEX 0x1801 36146
Port 3 PoE
Voltage
1 word 16 bits HEX 0x1802 36147
Port 4 PoE
Voltage
1 word 16 bits HEX 0x1803 36148
Port 5 PoE
Voltage
1 word 16 bits HEX 0x1804 36149
Port 6 PoE
Voltage
1 word 16 bits HEX 0x1805 36150
Port 7 PoE
Voltage
1 word 16 bits HEX 0x1806 36151
Port 8 PoE
Voltage
1 word 16 bits HEX 0x1807 36152
Port 9 PoE
Voltage
1 word 16 bits HEX 0x1808 36153
Port 10 PoE
Voltage
1 word 16 bits HEX 0x1809 36154
Port 11 PoE
Voltage
1 word 16 bits HEX 0x180A 36155
Port 12 PoE
Voltage
1 word 16 bits HEX 0x180B 36156
Port 13 PoE
Voltage
1 word 16 bits HEX 0x180C 36157
Port 14 PoE
Voltage
1 word 16 bits HEX 0x180D 36158
Port 15 PoE
Voltage
1 word 16 bits HEX 0x180E 36159
Port 16 PoE
Voltage
1 word 16 bits HEX 0x180F 36160
Port 17 PoE
Voltage
1 word 16 bits HEX 0x1810 36161
Catelog Name Data Type Interpretation Address
Offset (Hex)
Address
3X
Description
