128 EKI-7710 Series User Manual
Port Info Port 18 PoE
Voltage
1 word 16 bits HEX 0x1811 36162
Port 19 PoE
Voltage
1 word 16 bits HEX 0x1812 36163
Port 20 PoE
Voltage
1 word 16 bits HEX 0x1813 36164
Port 21 PoE
Voltage
1 word 16 bits HEX 0x1814 36165
Port 22 PoE
Voltage
1 word 16 bits HEX 0x1815 36166
Port 23 PoE
Voltage
1 word 16 bits HEX 0x1816 36167
Port 24 PoE
Voltage
1 word 16 bits HEX 0x1817 36168
Port 25 PoE
Voltage
1 word 16 bits HEX 0x1818 36169
Port 26 PoE
Voltage
1 word 16 bits HEX 0x1819 36170
Port 27 PoE
Voltage
1 word 16 bits HEX 0x181A 36171
Port 28 PoE
Voltage
1 word 16 bits HEX 0x181B 36172
Port 29 PoE
Voltage
1 word 16 bits HEX 0x181C 36173
Port 30 PoE
Voltage
1 word 16 bits HEX 0x181D 36174
Port 31 PoE
Voltage
1 word 16 bits HEX 0x181E 36175
Port 32 PoE
Voltage
1 word 16 bits HEX 0x181F 36176
PoE Current 1 word 16 bits HEX 0x1820 ~
0x183F
36177 ~
36208
PoE Current (mA)
Ex: poe current = 13
Received MODBUS
response: 0x000D
Port 1 PoE
Current
1 word 16 bits HEX 0x1820 36177
Port 2 PoE
Current
1 word 16 bits HEX 0x1821 36178
Port 3 PoE
Current
1 word 16 bits HEX 0x1822 36179
Catelog Name Data Type Interpretation Address
Offset (Hex)
Address
3X
Description
