Agilent 8159xA/S Optical Switch modules Switching Optical Routes
Agilent 8163A/B, 8164A/B, and 8166A/B User’s Guide, Fourth Edition 205
Agilent 8159xA/S Optical
Switch modules
The Agilent 8159xA/S Optical Switch family includes 1x2 Switch
modules, dual 1x2 Switch modules, 2x2 Switch modules, and 1x4
Switch modules.
Options
OptionSCI: For 8159xA modules, provides fixed SC/APC connector interfaces.
For 8159xS modules, provides fixed SC/PC connector interfaces.
OptionFCI: For 8159xA modules, provides fixed FC/APC connector interfaces for
R key (that is, narrow key only) connectors.
For 8159xS modules, provides fixed FC/PC connector interfaces.
Figure 127 Agilent 81592S Optical Switch module (Dual 1x2, straight contact connectors)
Table 12 The Agilent 8156xA Variable Optical Attenuator family
Module Description
81591A Optical Switch, 1x2, angled contact connectors
81592A Optical Switches, 2 independent 1x2 in one module, angled contact connectors
81594A Optical Switch, 2x2 non-blocking (crossover), angled contact connectors
81595A Optical Switch, 1x4, angled contact connectors
81591S Optical Switch, 1x2, straight contact connectors
81592S Optical Switches, 2 independent 1x2 in one module, straight contact connectors
81594S Optical Switch, 2x2 non-blocking (crossover), straight contact connectors
81595S Optical Switch, 1x4, straight contact connectors
