Agilent 8166A Specifications Specifications and Regulations Compliance
Agilent 8163A/B, 8164A/B, and 8166A/B User’s Guide, Fourth Edition 321
Agilent 8166A Specifications
The Agilent 8166A Lightwave Multichannel System displays 17
channels.
1
Modules designed for the HP 8153A Lightwave Multimeter are NOT
compatible with the Agilent 8166A Lightwave Multichannel System.
2
For code compatibility to the HP 8153A Lightwave Multimeter please
refer to the mainframe’s Programming Guide, part number 08164-
91016.
Display Graphical display 190 × 300 points visible,
monochrome.
Display Resolution (Power Meters) 0.0001 dB/dBm, 0.01 pW to 10 pW (depending on power
range), up to 6.5 digits (user definable).
Compatibility The Agilent 8166A supports all Agilent 8163A Series
modules.
1
Trigger True synchronous on all channels
Environmental
Storage temperature
Operating temperature
Humidity
−40°C to +70°C
0°C to +45°C
<95% R.H. from 0°C to +45°C
Power AC 100 - 240 V
± 10%, 50 - 60 Hz, 450 VA max.
GPIB interface
Function code
All modes and parameters accessible via GPIB interface
SCPI standard
2
Interfaces Parallel port (Centronics)
Serial port (RS232)
Number of Modules 17 Modules
Dimensions 240 mm × 430 mm × 580mm (9.5" × 17" × 23")
Weight net 23 kg (50.7 lbs); shipping 45 kg (94.8 lbs)
