Applications Working with Application Graphs
222 Agilent 8163A/B, 8164A/B, and 8166A/B User’s Guide, Fourth Edition
How to Lock Markers to the Curve
You can lock markers A and B to curves by performing the following
instructions:
1 Press the [Menu] softkey and move to <Lock to Curve>. A menu
displaying the options displayed in “The Lock to Curve Menu” on
page 222 appears.
2 Press the [A] softkey to lock marker A to a curve. The number
opposite
Marker A on curve:
is highlighted.
3 Use the cursor key to move to the legend number of the curve to
which you want to lock marker A.
4 Press Enter. Marker B will be locked to the same curve as marker A,
if it was assigned to curve 0 immediately before, that is, it was
unassigned immediately before.
5 If you want to assign marker B to another curve, press the [B]
softkey, use the cursor key to move to the legend number of the
curve to which you want to lock marker B, and press Enter.
6 Press Close to return to the graph.
Figure 140 The Lock to Curve Menu
