Installation and Maintenance Operating and Storage Environment
280 Agilent 8163A/B, 8164A/B, and 8166A/B User’s Guide, Fourth Edition
Operating Position
When operating the Agilent 8163A/B, Agilent 8164A/B, or Agilent
8166A/B choose a location that provides at least 75 mm (3 inches) of
clearance at the rear, and at least 25 mm (1 inch) of clearance at each
side. Failure to provide adequate air clearance may result in excessive
internal temperature, reducing instrument reliability. The instrument
should not be operated when mounted on its rear or side panels.
Figure 182 Correct Operating Position of the 8163A/B
Figure 183 Correct Operating Position of the Agilent 8164A/B
25 mm
(1 inch)
25 mm
(1 inch)
75 mm
(3 inches)
