Specifications and Regulations Compliance Agilent 8164B Specifications
320 Agilent 8163A/B, 8164A/B, and 8166A/B User’s Guide, Fourth Edition
Agilent 8164B Specifications
The Agilent 8164B Lightwave Measurement System displays five
channels.
1
Agilent 8163B Series modules are NOT compatible with the HP
8153A Lightwave Multimeter.
2
For code compatibility to the HP 8153A Lightwave Multimeter please
refer to the mainframe’s Programming Guide, part number 08164-
90B61.
Display Graphic color display 640 × 480 pixels visible.
VGA connector for external monitor.
Compatibility The Agilent 8164B mainframes support all HP 8153A Series
and Agilent 8163A/B Series modules.
1
Environmental
Storage temperature
Operating temperature
Humidity
−40° C to 70° C
10° C to 35° C
< 80% R.H. from 10° C to 35° C
Power AC 100 - 240 V
± 10%, 50 - 60 Hz, 280 VA max.
Dimensions 145 mm × 426 mm × 545 mm
(5.8" × 16.9" × 21.6")
Weight net, 20 kg (45 lb.), 23 kg (51 lb.), including modules.
GPIB interface
Function code
All modes and parameters accessible via GPIB interface.
SH1, AH1, T6, L4, SR0, RL1, PP0, DC1, DT0, C0.
SCPI standard;
2
GPIB Interface Performance max. 300 kB/s (burst data rate during read of 12001 points from
a power meter).
Trigger True synchronous on all channels
Trigger Bandwidth max. 100 kHz for triggering, and
max. 1 MHz (50% duty cycle) for external digital modulation.
RS232C Interface: max. baud rate 115200 bps
Parallel Printer Interface Centronics
Number of Modules 4 front-loadable Modules, 1 back-loadable Module
External Keyboard PS/2 connector (reserved for future use)
