Operating and Storage Environment Installation and Maintenance
Agilent 8163A/B, 8164A/B, and 8166A/B User’s Guide, Fourth Edition 281
Storage Position
The Agilent 8164A/B Lightwave Measurement System can be stored in
its operating position, as shown in Figure 182, or on its back legs as
shown in Figure 185. The back legs protect the connectors on the back
panel from damage.
CAUTION Before positioning the Agilent 8164A/B Lightwave Measurement
System on its back legs:
• make sure that the instrument is in stand-by mode, see page 76 and
• disconnect all connections to the back panel.
Figure 184 Correct Operating Position of the Agilent 8166A/B
25 mm
(1 inch)
25 mm
(1 inch)
75 mm
(3 inches)
