How to Measure Power Power Measurement
Agilent 8163A/B, 8164A/B, and 8166A/B User’s Guide, Fourth Edition 79
How to Measure Power
The Power Value
The <P> parameter displays the power measurement value. In MinMax
mode, this parameter changes to <
∆P>, the difference between
minimum and maximum power, see “How to Choose the MinMax
Mode” on page 95.
How to Set the Number of Digits
You can set the maximum number of digits that are used in power
measurement. This is the maximum number of digits after the decimal
point.
To change the number of digits to two:
1 Move to the Power Meter channel and press the [Menu] softkey.
2 Move to <Number of Digits> option and press Enter. You will see the
screen in Figure 41.
3 Move to 2 and press Enter.
4 Press the [Close] softkey to exit the menu.
Figure 41 The Number of Digits Menu
