Graphic Symbols in Softkey Menus
Softkeys are the six keys directly below the display. The are called Softkeys because
software determines the function assigned to each key in any given menu.
The following graphic symbols appear in the oscilloscope’s softkey menus. The softkey
menus appear at the bottom of the display, just above the six softkeys.
Rotate the Entry knob to adjust the parameter. The Entry knob is located on the front
panel. The symbol below the knob is illuminated when this control is active.
Rotate the Entry knob to select an item. Push the Entry knob or press the softkey to
activate the item or close the menu.
Press the softkey to display a pop-up menu. Press the softkey or rotate and push the
Entry knob to make an item active.
Option is selected but not active.
Option is selected and active.
Feature is on. Press the softkey again to turn the feature off.
Feature is off. Press the softkey again to turn the feature on.
Press the softkey to view the menu.
Press the softkey to return to the previous menu.
A dot on a softkey indicates that the action specified in the dialog will be
performed when the Entry knob is pushed (7000 Series only).
