3 Connecting to the Device Under Test
74 InfiniiVision Oscilloscopes User’s Guide
Active Probes
Most Agilent active probes are compatible with the AutoProbe interface. Active probes
that do not have their own external power supply require substantial power from the
AutoProbe interface. “Quantity Supported” indicates the maximum number of each type
of active probe that can be connected to the oscilloscope. If too much current is drawn
from the AutoProbe interface, an error message will be displayed, indicating that you
must momentarily disconnect all probes to reset the AutoProbe interface, then connect
only the supported quantity of active probes.
A
CTIVE PROBES
Active Probes Quantity Supported
1130A 1.5 GHz InfiniiMax amplifier, requires one or more
InfiniiMax probe heads: E2675A, E2668A, E2669A
2
1131A InfiniiMax 3.5 GHz Probe 2
1132A InfiniiMax 5 GHz Probe 2
1134A InfiniiMax 7 GHz Probe 2
1141A Differential Probe, 200 MHz, with 1142A power
supply
4
1144A Active Probe, 800 MHz, with 1142A power supply 4
1145A 2-Channel, 750 MHz Active Probe, with 1142A
power supply
2
1147A 50 MHz/15A AC/DC Current Probe 2
1156A 1.5 GHz Active Probe 4
1157A 2.5 GHz Active Probe 4
1158A 4 GHz Active Probe 4
N2772A Differential Probe, 20 MHz, with N2773A power
supply
4
N2774A (obsolete, replaced by N2782A) with N2775A
power supply
4
N2782A 50 MHz/30Arms AC/DC Current Probe, with
N2779A power supply
4
