To change the displayed size of the digital channels
1 Press the [D15-D0] key.
2 Press the size ( ) softkey to select how the digital channels are displayed.
The sizing control lets you spread out or compress the digital traces vertically on the
display for more convenient viewing.
To switch a single channel on or off
1 With the Digital Channel Menu displayed, rotate the Entry knob to select the desired
channel from the popup menu.
2 Press the softkey that is directly below the popup menu to switch the selected
channel on or off.
To switch all digital channels on or off
1 Press the [D15-D0] key to switch the display of the digital channels on or off. The
Digital Channel Menu will be displayed above the softkeys.
The digital channels are displayed when this key is illuminated.
If you want to switch the digital channels off, and the Digital Channel Menu is not
already displayed, you will have to push the [D15-D0] key twice to switch the digital
channels off. The first push displays the Digital Channel Menu, and the second push
switches the channels off.
To switch groups of channels on or off
1 Press the [D15-D0] key on the front panel if the Digital Channel Menu is not already
displayed.
2 Press the Turn off (or Turn on) softkey for the D15 - D8 group or the D7 - D0 group.
Each time you press the softkey, the softkey’s mode toggles between Turn on and Turn
off.
