2 Initial Setup
50 InfiniiVision Oscilloscopes User’s Guide
The battery will last approximately 1.75 hours before requiring recharging. Operating time
depends on the oscilloscope configuration.
Operating
When operating with the internal battery, the operating temperature should be in the
range from -10C to 50C, 80% relative humidity. Low temperatures temporarily reduce
battery capacity.
1 Make sure battery is charged before use. See “Charging the Battery” below.
Caution indicator. Illuminates (amber) when running
on the internal battery. See “Operating” below.
Battery power indicator. Turns from green to red when
there is 15 to 20 minutes of battery power remaining.
Charging indicator. Illuminates when the battery is
charging. Turns off when the battery is fully charged or
when the charger is disconnected.
