2 Initial Setup
42 InfiniiVision Oscilloscopes User’s Guide
7000 Series Overlay
A front panel overlay which labels the controls is available in Simplified Chinese,
Traditional Chinese, and Japanese. The overlay is included when the localization option is
chosen at time of purchase.
Remove the protective backing to expose the adhesive, align the label with the top and
left edge of the front panel, and press the overlay into place.
To remove the label, carefully pull it away using the tab at the lower right corner.
The overlays can also be ordered separately at www.parts.agilent.com using the
following part numbers:
Part number
Description
54695-94311 2CH Overlay - Simplified Chinese
54695-94312 4CH Overlay - Simplified Chinese
54695-94313 2CH Overlay - Traditional Chinese
54695-94314 4CH Overlay - Traditional Chinese
54695-94315 2CH Overlay - Japanese
54695-94316 4CH Overlay - Japanese
