Agilent Technologies InfiniiVision 5000 Series User Manual

Measurements and Math Functions 6
InfiniiVision Oscilloscopes User’s Guide 213
Post Acquisition Processing
In addition to changing display parameters after the acquisition, you can perform all of the
measurements and math functions after the acquisition. Measurements and math functions will
be recalculated as you pan and zoom and turn channels on and off. As you zoom in and out on a
signal using the horizontal sweep speed knob and vertical volts/division knob, you affect the
resolution of the display. Because measurements and math functions are performed on displayed
data, you affect the resolution of functions and measurements.
