Functional description
138 MPR-e and MSS-1c User Manual 3DB19901EFAA Edition 01
Figure 3.48 shows an MPT-HC with an embedded diplexer.
Figure 3.48 — MPT-HC housing (embedded diplexer)
MPT-XP Not supported
MPT-XP-HQAM Not supported
Table 3.38 — (Continued)MPT ODUs that support an embedded diplexer
Radio Frequency range
Warning: To mount a 6 GHz MPT-HC with internal diplexer in a 1+1 configuration with a
MPT-HC with external diplexer, the MPT with internal diplexer must be the Main unit and
the MPT with external diplexer must be the Spare unit, see Figure 3.49. If the units are
mounted the other way, the cabling will cause interference; see Figure 3.50.
