Functional description
MPR-e and MSS-1c User Manual 3DB19901EFAA Edition 01 157
A default time-out period may be suggested at the operator interface, even if it could be
modified on user-needs basis.
After the NE reset, the activation of each loopback point is lost and must be recreated again
if needed, starting with a new time-out period.
3.10.8.13 — MPR-A: Unlicensed radio for 9558HC
The JF6-9558HC/6933B-9558HC (9558HC) unlicensed radio provide fast deployment of
service with microwave radio. No license and small antennas (no FCC and Industry Canada
(IC) requirements) allow immediate Turn-Up. The 9558HC unlicensed radio can not be
upgraded to licensed.
See the Equipping Options Drawing for unlicensed radio configurations and equipping
options, found in the Alcatel-Lucent 9500 MPR-A Engineering Support Documentation.
The 9558HC unlicensed radio operate in the 5725-5850 Information, Scientific, and
Medical (ISM) band in accordance with FCC Part 15.247 and IC RSS-210. This unlicensed
radio, although operating in the same band as a spread spectrum radio, operates using
narrower bandwidths than spread spectrum. Advantages, disadvantages, and antenna
recommendations for the unlicensed radio follow:
Advantages:
• Fast installation and Turn-Up
• Between 6.6 — 185 Mb/s user configurable data payload capacity consisting of a
combination of DS1, DS3, and/or Ethernet traffic
• Field expandable to higher capacities.
• Common network management with licensed radios.
• Common spares and training with licensed radios
Note: Changes or modifications not expressly approved by Alcatel-Lucent could void the
authority to operate the JF6-9558HC/6933B-9558HC unlicensed radio.
Note: Installation, Turn-Up, Maintenance, and Operation Instruction supplied with the
JF6-9558HC/6933B-9558HC unlicensed radio require strict adherence for continued part
15 of the FCC Rules and IC RSS-210 compliance.
Table 3.43 — Unlicensed radio
Transceiver FCC ID Industry Canada ID
9558HC JF6-9558HC 6933B-9558HC
