212 MPR-e and MSS-1c User Manual 3DB19901EFAA Edition 01
The Apache Server, installed with the WebEML from the TCO Software Suite R5.2 DVD-
ROM, is started with NEtO as the default FTP/SFTP server.
To download and activate software:
1. If you will be using FTP, check that the following parameters have been correctly
setup:
• Server Address: PC address
• Username: anonymous
• Password: anonymous
• Port: 21
If you will be using SFTP, check that the following parameters have been correctly
setup:
• Server Address: PC address
• Fingerprint: F1:A4:96:42:97:A3:2B:45:7E:D6:4C:58:5D:00:77:42
• Username : swp-administrator1
• Password: not displayed
Click on the Reset to Default button to recall the default connection settings if an
error is made.
2. Click on the Check button. If trouble occurs, check the NEtO Servers Manager
window to verify that the FTP/SFTP Server is on.
If the fingerprint is not filled in manually, the MCT displays the fingerprint in a popup
for confirmation, see Figure 4.29.
Figure 4.35 — SFTP fingerprint window
Warning: An FTP Server must be installed on the PC containing the Software Package.
The PC's firewall (Microsoft's default firewall) may prevent the download from starting up.
