• Number of Bytes
• Number of Frames
• Discarded Frames
• Errored Frames
• Unicast Frames
• Multicast Frames
• Broadcast Frames
The counters are shown in the following formats:
• bar
• graphical
• tabular
An example of the Traffic Port Counters screen is given in Figure 4.149.
Note: The Egress Discarded Frames counter is associated with 100Base-Tx. It has no
meaning when the MPR-e is working at 1000B-T/1000B-SX
