AT-SBx908 Gen2 Switch Installation Guide
105
Figure 75. Connecting the Negative (-) Power Wire with a Right Angle
Terminal
Check to see if there are any exposed copper strands coming from
the installed wires. When this installation is done correctly there
should be no exposed copper wire strands extending from the
terminal block. Any exposed wiring can conduct harmful levels of
electricity to persons touching the wires. E12
8. With a #2 Phillips-head screwdriver, tighten the handle locking screw
to secure the power supply to the chassis. See Figure 76 on page 106.
