Chapter 6: Replacing Modules
132
Figure 94. Lifting the Locking Handle on the AT-SBxPWRSYS2 AC Power
Supply
4. Carefully pull on the locking handle to slide the power supply from the
chassis. Refer to Figure 95 on page 133.
Warning
The power supply is heavy. Use both hands to hold the module as
you remove it from the chassis.
