AT-SBx908 Gen2 Switch Installation Guide
141
Figure 103. Reinstalling the Nut and Washer on the Grounding Post
If you did not perform step 3 to loosen the retaining screw on the
power supply, perform the step before continuing.
11. Lift the locking handle and slide the power supply from the chassis.
Refer to Figure 104 on page 142.
The power supply is heavy. Use both hands to hold the module as
you remove it from the chassis.
