Appendix A: Technical Specifications
160
Physical Specifications
Dimensions (H x W x D)
Table 9 lists the product dimensions.
Weights
Table 10 lists the weights of the components.
Table 9. Product Dimensions
AT-SBx908 Gen2 Chassis 133 x 441 x 473 cm
(5.22 x 17.34 x 18.64 in.)
(H x W x D)
AT-SBxPWRSYS2 AC Power
Supply System
4.34 x 10.16 x 32.21 cm
(1.71 x 4.00 x 12.68 in.)
AT-SBxPWRSYS1-80 DC Power
Supply System
4.34 x 10.16 x 32.21 cm
(1.71 x 4.00 x 12.68 in.)
AT-XEM2-12XT Line Card
AT-XEM2-12XS Line Card
AT-XEM2-4QS Line Card
109.52 x 39.12 x 155.45 cm
(4.31 x 1.54 x 6.12 in.)
AT-FAN08 Fan Module 69.09 x 164.62 x 86.36 cm
(2.72 x 6.48 x 3.40 in.)
Table 10. Product Weights
AT-SBx908 Gen2 Chassis 15.81 kg (34.85 lb.)
AT-SBxPWRSYS2 AC Power
Supply System
2.70 kg (6.05 lb.) with power cord
AT-SBxPWRSYS1-80 DC Power
Supply System
1.9 kg (4.2 lb)
AT-XEM2-12XT Line Card 0.75 kg (1.65 lb.)
AT-XEM2-12XS Line Card 0.75 kg (1.65 lb.)
AT-XEM2-4QS Line Card 0.66 kg (1.45 lb.)
AT-FAN08 Fan Module 0.72 kg (1.60 lb.)
