18
www.analogway.com
USER MANUAL
4 Introducing Midra™ 4K
Before setting up the Midra™ 4K for the first time, please read through all of the documentation to become
familiar with its powerful features. The Midra™ 4K is an ideally tailored video production tool for small and
mid-size live event staging and fixed installation applications.
4.1 Midra™ 4K product range
The Midra™ 4K product range includes four models:
- QuickVu 4K
- QuickMatrix 4K
- Pulse 4K
- Eikos 4K
All models have similar front panels and rear panels, they offer the same capabilities in terms of inputs and
outputs plugs. The models have different operating modes and capabilities.
Note: The Eikos 4K is more powerful than other models as it is able to use Images or Live Inputs as Background content.
Other models can only use Images as Background content.
Midra™ 4K Models Operating modes Output 1 Output 2
QuickVu 4K Mixer mode only (S-Aux) 1 Mixing layer AUX
QuickMatrix 4K Matrix mode only (S-S) 1 Mixing layer 1 Mixing layer
Pulse 4K
Mixer mode (S-Aux) 2 Mixing layers AUX
Matrix mode (S-S) 1 Mixing layer 1 Mixing layer
Eikos 4K
Mixer mode (S-Aux) 2 Mixing layers AUX
Matrix mode (S-S) 1 Mixing layer 1 Mixing layer
Edge-blending mode 2 Mixing layers
Table 1 - Midra™ 4K family
For more information, see 6.3 Operating modes page 32.
All Midra™ 4K units can be fully operated from their front panel.
